Microphone Cable
A high-quality, versatile microphone cable designed for professional audio applications. it features oxygen-free copper conductors and 100% braided shielding for clear, noise-free signal transmission in both live and studio environments.
General Data
| Properties | Analog |
| Properties | OFC oxygen free copper |
| Application Area | Stage / live |
| Application Area | outdoor / indoor |
| Application Area | Studio / Broadcast |
| Application Area | Installation |
| Application Area | ELA 100 V |
| Application | Microphone Cable |
| Colour | black |
| UV-resistant | yes |
Technical & Electrical Data
| Signal transmission | symmetrical |
| Construction | 2(2L12YS0,34mm²)(ST) |
| Jacket material | PVC |
| Jacket Ø [mm] | 6.5 |
| Number of Channels | 1 |
| Inner conductor | 2 |
| Inner conductor cross-section [mm²] | 0.34 |
| Inner conductor Ø [mm] | 0.66 |
| AWG | 22 |
| Shielding | Copper braided shielding with 0.10 mm indiv. Strands |
| Shielding factor [%] | 100 |
| Copper strands | 19 |
| Copper strand Ø [mm] | 0.15 |
| Conductor insulation material | PE |
| Conductor insulation Ø [mm] | 1.50 |
| Weight per 1 m [g] | 50 |
| Fire load per m [kWh] | 0.22 |
